4 Inch Capacitive Touch Screen

Name: China Customized 4 Inch Capacitive Touch Screen Suppliers, Manufacturers, Factory - Made in China - Head Sun
Brand: Head Sun
SKU: 158316108

4 Inch Capacitive Touch Screen
Model：FT6940
Brand：Head Sun Co., Ltd
Border color：Black
Structure ：G+F
Interface：IIC
Touch points：Single Point + gesture
Total Thickness：0.95mm
Outline Dimension：62.81±0.05mm*105.1±0.05mm

Send Inquiry

Description

Product Description:

Product Drawing:

1 Product Drawing

Product Specifications:

4 Inch Capacitive Touch Screen
Structure Characteristics
Product Size	4Inch
Product Structure	G+F
Outline Dimension	62.81±0.05mm*105.1±0.05mm
View Area	52.44±0.15mm*87.0±0.15mm
Total Thickness	0.95mm
Electrical Characteristics
IC Type	FT6336U
Touch of points	Single Point + gesture
Interface	IIC
Operating Voltage
Special Performance Options
Glove Mode
Waterproof Level
Antistatic Test
Outdoor Products
Riot Level / IK Grade
Waterproof Operation Mode
Material Characteristics
Cover Lens	Panda, Thickness=0.70mm
ITO-FLIM	Thickness 0.125mm
OCA	Thickness 0.125mm
Environmental Characteristics
OperatingTemperature	-20~60℃
Storage Temperature	-30~70℃
Reliability Test Conditions
High-temperature Storage	T=70℃, 72H
Low-temperature Storage	T=-30℃, 72H
High-temperature\High-humidity Storage	T=60℃ 90%,72H
Heat Shock	(-20 ﾟ C(30min)←(5min Max.)→60 ﾟ C(30min))=50 Set
Electro Static Discharge	Air discharge :±8KV,Contact discharge :±4KV
Hardness	≥6H
Ball Drop Test	64g 40cm,No breakage at the center point for 3 times
FPC Bending Test	The bending radius R1.0 mm, more than three times
Note: ①After the test under the above reliability conditions, the specimen should be stored in a standard environment for 24 hours before the functional test is OK. ②The reliability test should be performed with no D.C. power supplied and the touch panel stored on the flat plate. ③The standard condition presents 25±10°C of the temperature, 55±30%of the relative humidity, and 96±10 kPa of the atmospheric pressure. ④The reliability test should be performed on the touch panel by itself.

Product Applications:

Our touch screens are widely used for industrial control equipments, smart home appliances, door locks, bracelets, smart watch, wearable devices, automotive, boats & ships, medical equipments, POS terminals, game machine and other fields. This 4 Inch Capacitive Touch Screen is customized for POS machine.

2 Product Application

Q:What is the advantages of G+G structure?

A:1.It is hard and not easy to scratch.

1. It is corrosion-resistant.

2. The light transmittance is high, exceeding 91%.

Q:Which brands are mainly used for cover plates?

AGC, Coring, Panda, etc.

1. Which ICs are mainly used?

ILITEK, Focaltech, Goodix, etc.

Q:Does the touch screen comply with the RoHS standard?

A:Yes.

Q:What is the life span of the touch screen?

A:Our touch screen support over 50 billion times touch.

Q:What’s the difference between projected capacitive touch panel and surface capacitive touch panel?

A:Projected capacitive touch panel can support multi-touch,but surface capacitive touch panel only support single point touch. And the projected capacitive touch panel can support touch with glove, can be operated through a layer of cover glass.

Our Honor and Certifications: Head Sun has successfully passed the high-tech enterprise, audited supplier and ISO9001 quality management system assessment.

6 Our honor and certification
