1.4 Inch Touch LCD Screen
1.4 Inch Touch LCD Screen
Model：FT6884
Structure ：G+F
Interface：IIC
Touch points：1 Point (Single Point)
Total Thickness：TP:1.85mm
Outline Dimension：31.56±0.05mm*38.86±0.05mm
Description
Product Description:
Product Drawing:
Product Specifications:
1.4 Inch Touch LCD Screen | |
Structure Characteristics | |
Product Size | 1.4Inch |
Product Structure | G+F |
Outline Dimension | 31.56±0.05mm*38.86±0.05mm |
View Area | 25.70±0.1mm*25.70±0.1mm |
Total Thickness | TP:1.85mm |
IC Type | CST816S |
Touch of points | 1 Point (Single Point) |
Interface | IIC |
Cover Lens | Panda, Thickness=1.6mm |
ITO-FLIM | Sensor Thickness:0.25mm |
OCA | |
Storage Temperature | -30~80℃ |
High-temperature Storage | T=70℃, 72H |
Low-temperature Storage | T=-30℃, 72H |
High-humidity Storage | T=60℃ 90%,72H |
Heat Shock | (-20 ﾟ C(30min)←(5min Max.)→60 ﾟ C(30min))=50 Set |
Electro Static Discharge | Air discharge :±8KV,Contact discharge :±4KV |
Hardness | ≥6H |
Product Applications:
Our touch screens are widely used for industrial control equipments, smart home appliances, door locks, bracelets, smart watch, wearable devices, automotive, boats & ships, medical equipments, POS terminals, game machine and other fields. This 1.4 Inch Touch LCD Screen is customized for smart watch.
Our Advantages:
1. Specialized in display module with more than 10 years experience.
2.One-stop Solution
LCD panel cutting & etching.We have own cutting and etching factories and cut & etch the LCD panel for big brands.
3.LCD panel&Driver IC. We are the direct distributor, we can guarantee supply.
4. Accepting OEM & ODM. Customizing according to different condition.
5. Excellent service and high quality products to meet or even exceed our customer's expectations.
6.Owning factories to do LCD module assembly, ISO9001.
Our Honor and Certifications: Head Sun has successfully passed the high-tech enterprise, audited supplier and ISO9001 quality management system assessment.
