4 Inch Square LCD Display
4 Inch Square LCD Display
Model：4.0
Outline Dimension: 74.83mm*78.98mm*1.56mm
Description
Product Drawing:
Product Specifications:
4 Inch Square LCD Display | |
Product Structure | |
Outline Dimension | 74.83mm*78.98mm*1.56mm |
View Area | 71.93mm*71.93mm |
Interface | 4Lane-MIPI、RGB |
Environmental Characteristics | |
OperatingTemperature | -20～ 60°C |
Storage Temperature | -30～ 70°C |
High-temperature Storage | T=70℃, 72H |
Low-temperature Storage | T=-30℃, 72H |
High-humidity Storage | 90%,72H |
Heat Shock | (-20 ﾟ C(30min)←(5min Max.)→60 ﾟ C(30min))=50 Set |
Electro Static Discharge | Air discharge :±8KV,Contact discharge :±4KV |
Hardness | ≥6H |
Ball Drop Test | 64g 40cm,No breakage at the center point for 3 times |
FPC Bending Test | The bending radius R1.0 mm, more than three times |
Product Applications:
Our LCDs are widely used for industrial control equipment, smart home appliances, door locks, smart watch, wearable devices, automotive, boats & ships, medical equipments, POS terminals, game machine and other fields. This 4 inch square LCD Display is specially customized for most kinds of smart devices.
Why Choose US?
1.Experienced Team
2.Accept OEM & ODM.
3.Modern Technology
4.One-stop Solution
Exhibitions:
FAQ:
Q: What is the minimum order?
A: Our company mainly deals in wholesale business, but we accept sample order for the first time.
Q: How is your production management and quality control system?
A: All our product process follows up ISO9001: income quality checking, in process quality checking, final product quality checking. The strict implementation of ISO9001 assures to provide error – free products to our customers.
Our Honor and Certificates: Head Sun is a national high-tech enterprise, audited supplier and ISO9001 quality management system assessment.
